攪拌車的四項工作原理
攪拌車攪拌功能原理：
Mixing function principle of mixer truck:
取力器將發動機的動力通過小傳動軸帶動液壓泵液壓馬達轉動，經過減速機帶動攪拌桶轉動。在運輸混凝土的途中，需要保持攪拌罐每分鐘1-3轉的低速轉動，以保證混凝土的勻質,同時防止混凝土的離析,稱為攪動（俗稱攪拌）。
The power take-off drives the hydraulic motor of the hydraulic pump to rotate through the small transmission shaft, and drives the mixing drum to rotate through the reducer. During the transportation of concrete, it is necessary to keep the mixing tank rotating at a low speed of 1-3 revolutions per minute to ensure the uniformity of concrete and prevent concrete segregation, which is called stirring (commonly known as mixing).
攪拌車裝料功能原理：
Loading function and principle of mixer truck:
攪拌車在裝混凝土的時候攪拌罐轉速較快，速度為每分鐘6-10轉，混凝土通過裝料系統從筒口導管進入攪拌筒，并在螺旋葉片引導下，流向攪拌筒的中下部。注意：裝料時與運輸過程中罐體的轉動方向應保持一致，否則在運輸過程中會(huì )將混凝土卸出。
When the mixer truck is loading concrete, the speed of the mixing tank is fast, with a speed of 6-10 revolutions per minute. The concrete enters the mixing drum from the barrel opening conduit through the loading system and flows to the middle and lower part of the mixing drum under the guidance of spiral blades. Note: the rotation direction of the tank body during loading shall be consistent with that during transportation, otherwise the concrete will be unloaded during transportation.
攪拌車卸料功能原理：
Unloading function and principle of mixer truck:
攪拌車在卸料時，發動機將動力通過取力器，液壓泵，減速機等傳輸到攪拌罐，帶動罐體轉動，速度為3-14轉/分；混凝土在 葉片螺旋運動的頂推作用下向筒口方向移動，經過攪拌車的卸料斗卸出。此時罐體的轉動方向與進料時的方向相反。
When the mixer truck is unloading, the engine transmits the power to the mixing tank through the power take-off, hydraulic pump and reducer to drive the tank to rotate at a speed of 3-14 rpm; The concrete moves towards the cylinder mouth under the pushing action of the blade spiral movement and is discharged through the discharge hopper of the mixer truck. At this time, the rotation direction of the can body is opposite to that during feeding.
攪拌車清洗功能原理：
Mixing truck cleaning function principle:
通過制動系統的儲氣筒給水罐加壓，水流經過加壓清洗攪拌罐系統，裝料口，卸料系統等。
Pressurize the water tank through the air reservoir of the braking system, and the water flows through the pressurized cleaning mixing tank system, loading port, unloading system, etc.
Mixing function principle of mixer truck:
取力器將發動機的動力通過小傳動軸帶動液壓泵液壓馬達轉動，經過減速機帶動攪拌桶轉動。在運輸混凝土的途中，需要保持攪拌罐每分鐘1-3轉的低速轉動，以保證混凝土的勻質,同時防止混凝土的離析,稱為攪動（俗稱攪拌）。
The power take-off drives the hydraulic motor of the hydraulic pump to rotate through the small transmission shaft, and drives the mixing drum to rotate through the reducer. During the transportation of concrete, it is necessary to keep the mixing tank rotating at a low speed of 1-3 revolutions per minute to ensure the uniformity of concrete and prevent concrete segregation, which is called stirring (commonly known as mixing).
攪拌車裝料功能原理：
Loading function and principle of mixer truck:
攪拌車在裝混凝土的時候攪拌罐轉速較快，速度為每分鐘6-10轉，混凝土通過裝料系統從筒口導管進入攪拌筒，并在螺旋葉片引導下，流向攪拌筒的中下部。注意：裝料時與運輸過程中罐體的轉動方向應保持一致，否則在運輸過程中會(huì )將混凝土卸出。
When the mixer truck is loading concrete, the speed of the mixing tank is fast, with a speed of 6-10 revolutions per minute. The concrete enters the mixing drum from the barrel opening conduit through the loading system and flows to the middle and lower part of the mixing drum under the guidance of spiral blades. Note: the rotation direction of the tank body during loading shall be consistent with that during transportation, otherwise the concrete will be unloaded during transportation.
攪拌車卸料功能原理：
Unloading function and principle of mixer truck:
攪拌車在卸料時，發動機將動力通過取力器，液壓泵，減速機等傳輸到攪拌罐，帶動罐體轉動，速度為3-14轉/分；混凝土在 葉片螺旋運動的頂推作用下向筒口方向移動，經過攪拌車的卸料斗卸出。此時罐體的轉動方向與進料時的方向相反。
When the mixer truck is unloading, the engine transmits the power to the mixing tank through the power take-off, hydraulic pump and reducer to drive the tank to rotate at a speed of 3-14 rpm; The concrete moves towards the cylinder mouth under the pushing action of the blade spiral movement and is discharged through the discharge hopper of the mixer truck. At this time, the rotation direction of the can body is opposite to that during feeding.
攪拌車清洗功能原理：
Mixing truck cleaning function principle:
通過制動系統的儲氣筒給水罐加壓，水流經過加壓清洗攪拌罐系統，裝料口，卸料系統等。
Pressurize the water tank through the air reservoir of the braking system, and the water flows through the pressurized cleaning mixing tank system, loading port, unloading system, etc.
